Spec sheets and Manuals

Keybrick One
Value / Description
Size64 x 31.5 x 29.2 mm
Weight~50g
Battery capacity1200mAh
Charging5V at up to 1000mA
Ouput characteristics9.3V nominal in Boost mode
7.8V nominal in Normal mode
6.3V nominal in ECO mode
Output power15W max.
Standby battery life> 1 year
when stored fully charged initially

User manual

Note: French translations are currently being redacted.

Keybrick One Lite

Keybrick One Lite

Value / Desciption
Size64 x 31.5 x 29.2 mm
Weight~20g
PowerbankUSB Power Delivery compatible powerbank with support for 9V output negotiation.
Ouput characteristics8.4V
Output power15W max.

User manual

Note: French translations are currently being redacted.

LEGO® set compatibility for Keybrick One Series:

Keybrick One and Keybrick One Lite are compatible with all sets using the LEGO® Powered Up Hub 88009. Currently we know of the following sets:

  • LEGO® Ideas Grand Piano 21323
  • LEGO® Crocodile Locomotive 10277
  • LEGO® Disney Train 71044
  • LEGO® City Passenger Train 60197
  • LEGO® City Passenger Express Train Set 60337
  • LEGO® City Cargo Train 60198
  • LEGO®City Freight Train 60336
  • LEGO® App Controlled Batmobile 76112

The following sets are designed to be extended using the LEGO® Powered Up Hub 88009. The hub is not included in these sets themselves.

  • LEGO® Holiday Main Street 10308
  • LEGO® Loop Coaster 10303
  • LEGO® Haunted House 10273
Keybrick Move
Value / Description
Size63.7 x 37.1 x 31.6 mm
Weight~54g
Battery capacity1200mAh
Charging5V at up to 1000mA
Ouput characteristics9.3V nominal in Boost mode
7.8V nominal in Normal mode
6.3V nominal in ECO mode
Output power15W max.
Standby battery life> 1 year
when stored fully charged initially

User Manual

Note: French translations are currently being redacted.

Keybrick Move Lite
Value / Desciption
Size63.7 x 37.1 x 31.6 mm
Weight~20g
PowerbankUSB Power Delivery compatible powerbank with support for 9V output negotiation.
Ouput characteristics8.4V
Output power15W max.

User Manual

Note: French translations are currently being redacted.

LEGO® set compatibility for Keybrick Move Series:

Keybrick Move and Keybrick Move Lite are compatible with all sets using the LEGO® Powered Up Hub 88006 also known as Move Hub. Currently we know of the following sets:

  • LEGO® Boost Robotics Set 17101
  • LEGO® Star Wars™ Boost Droide 75253

USB Powerbank compatibility for Keybrick One Lite and Keybrick Move Lite:

In order for Keybrick One Lite / Keybrick Move Lite to function properly, a compatible power bank or power source is required. In order to provide the required output voltage Keybrick One Lite / Keybrick Move Lite will negotiate the output power with the plugged in source and the indicator light will switch from red to blue when the output voltage could be negotiated .

Here’s a non-exhaustive list of power banks and power supplies that we have tested with and that were found to work:

  • Anker Nano Powerbank 10000mAh PD 30W
  • Anker PowerCore+ 26800 PD 45W Powerbank
  • Anker PowerCore 10000 Redux
  • Asus USB-C Notebook Charger 0A001-01090000
  • Baseus 65W 26800mAh PD Powerbank
  • Baseus PD 100W 20000mAh slim Powerbank
  • Charmast Powerbank PD 65W 23800mAh
  • DELL USB-C 65W Laptop Charger
  • DELL USB-C 45W Laptop Charger
  • evatronic PD Pioneer 20000mAh Powerbank
  • HAMA PD0-HD 10000mAh Powerbank
  • INIU 22.5W Fast Charging PD3.0 Powerbank 10000mAh
  • Lenovo GO USB-C Powerbank
  • Lenovo 65W Travel Laptop Charger 4X20V24678
  • Lenovo 64W Type C Laptop Charger 4X20M26272
  • UGREEN 100W Powerbank 20000mAh
  • VEGER Powerbank 22.5W PD3.0
  • Samsung Powerbank 20 Ah

Keybrick One Lite and Keybrick Move Lite are designed to withstand input voltage up to 21V so you can safely try power banks and power supplies by plugging them into Keybrick One Lite / Keybrick Move Lite and seeing if the indicator light switches to blue. Do not perform these trials when having Keybrick One Lite / Keybrick Move Lite mounted in your LEGO® Powered Up Hub 88009 / LEGO® Powered Up Hub 88006 as a safety measure.
